AMP MIC POSITIONS

where to place a mic in front of a guitar cab and how each spot sounds — after the Shure chart

Built as a memo rather than a table: the thing worth hanging it up for reads across the room, with the full reference in smaller type below it.

Three sizes in one archive — from a sheet on the fridge to a poster on the wall.

Formats: A4 · A3 · A2
What you get: Print-ready PDFs, one per size, with every letterform converted to outlines — nothing to install, nothing to shift.
Subject: music · beginners · memo · music room

Placements, tonal balance and comments follow the electric-guitar chart in Shure’s “Microphone Techniques for Recording”; centimetres are converted from its inches and feet. Cab and distances share one scale: Fender Deluxe Reverb, 622 × 241 mm from above, 305 mm speaker.

A VOICE-SHAPED INSTRUMENT

The Shure guide opens the section with a surprise: in character the electric guitar is close to the human voice, so a microphone shaped for vocals works well on it. The same mic that records singing can stand in front of the cab.

Distance flips the tone: one inch from the grille sounds bassy, three feet away sounds thin with the bass cut away. The same speaker, the same amp — the whole choice lies between those points.

On the sheet

Placements, tonal balance and comments follow the electric-guitar chart in Shure’s “Microphone Techniques for Recording”; centimetres are converted from its inches and feet. Cab and distances share one scale: Fender Deluxe Reverb, 622 × 241 mm from above, 305 mm speaker.
Colour carries meaning, but meaning never rests on colour alone — the sheet reads in black and white.
Nothing about how it was made: the sheet carries only what the reader needs.

Printing

Three sizes in the archive: A4 — 210×297 mm, A3 — 297×420 mm, A2 — 420×594 mm.
All text is converted to outlines. No fonts to install, and nothing shifts on another machine.
White background and sparing fills — it prints on a home printer without draining the cartridge.
Margins of at least 10 mm: a home printer cannot print to the edge.
No stroke thinner than 0.3 mm, so nothing disappears in print.

Why the numbers can be trusted. Every countable number here is computed from data rather than typed in, and the sheet must pass 7 independent checks before it is allowed to build — how many items there are, the order they come in, and the claim in the highlighted box itself. If one fails, there is no file.
